產品牌號
Produst Grades

TN-2

TN-3

TN-4

TN-5

TN-6

TN-7

TN-7H

TN-8L

TN-8

TN-8H

TN-9

TN-9H

TN-10

TN-10H

TN-11L

TN-11

TN-12L

TN-12

剩餘磁感位強度 Br
Residual Induction

(mT)
(KGs)

200-300
2.0-3.0

370-420
3.5-4.5

420-470
4.0-5.0

480-520
4.5-5.5

550-600
5.5-6.0

600-650
6.0-6.5

550-600
5.5-6.0

600-650
6.0-6.5

600-650
6.0-6.5

600-650
6.0-6.5

650-700
6.5-7.0

650-700
6.5-7.0

650-700
6.5-7.0

650-700
6.5-7.0

680-730
6.8-7.3

680-720
6.8-7.2

720-780
7.2-7.8

700-750
7.0-7.5

矯頑力 Hcb
Coercive Force

(KA/m)
(KOe)

160-240
2.0-3.0

200-280
2.5-3.5

200-280
2.5-3.5

200-320
2.5-4.0

280-400
3.5-5.0

320-400
4.0-5.0

320-440
4.0-5.5

320-400
4.0-5.0

360-440
4.5-5.5

440-520
5.5-6.5

360-480
4.5-6.0

360-480
4.5-6.0

360-480
4.5-6.0

400-480
5.0-6.0

360-440
4.5-5.5

400-480
5.0-6.0

360-440
4.5-5.5

360-520
4.5-6.5

內稟矯頑力  Hcj
Intrinsic Coercve Force

(KA/m)
(KOe)

400-560
5.0-7.0

520-600
6.5-7.5

520-600
6.5-7.5

520-640
6.5-8.0

560-680
7.0-8.5

640-720
8.0-9.0

960-1120
12.0-14.0

560-640
7.0-8.0

640-720
8.0-9.0

800-960
10.0-12.0

640-720
8.0-9.0

720-880
9.0-11.0

680-760
8.5-9.5

880-1040
11.0-13.0

520-600
6.5-7.5

680-800
8.5-10.0

520-600
6.5-7.5

640-800
8.0-10.0

最大磁能積 (BH)max
Max.Energy Product

(KJ/m3)
(MGOe)

12-24
1.5-3.0

20-28
2.5-3.5

28-36
3.5-4.5

36-44
4.5-5.5

44-52
5.5-6.5

52-60
6.5-7.5

52-60
6.5-7.5

60-68
7.5-8.5

60-68
7.5-8.5

60-68
7.5-8.5

64-72
8.0-9.0

64-72
8.0-9.0

72-80
9.0-10.0

72-80
9.0-10.0

76-84
9.5-10.5

76-84
9.5-10.5

84-92
10.5-11.5

84-90
10.5-11.3

可逆磁導率 (μrec)
Permeability

(μH/M)

1.20

1.20

1.20

1.20

1.20

1.20

1.20

1.20

1.20

1.20

1.20

1.20

1.20

1.20

1.20

1.20

1.20

1.20

平均可逆溫度系数
Temperature Coefficient
of Br

(%/°C)

-0.10

-0.10

-0.11

-0.11

-0.10

-0.12

-0.12

-0.12

-0.12

-0.13

-0.10

-0.10

-0.10

-0.13

-0.10

-0.10

-0.11

-0.10

飽和磁化場 Hs
Magnetizing Field to
＞95％ Saturation

(KA/m)
(KOe)

≧1600
≧20

≧1600
≧20

≧1600
≧20

≧1600
≧20

≧1600
≧20

≧1600
≧20

≧1800
≧22

≧1600
≧20

≧1600
≧20

≧2000
≧25

≧1600
≧20

≧1600
≧20

≧1600
≧20

≧2000
≧25

≧1600
≧20

≧1600
≧20

≧1600
≧20

≧1600
≧20

最大工作溫度
Max.Operating
Temperature

(°C)

150

150

150

150

160

160

180

150

160

180

160

180

150

180

150

160

150

160

密度p
Density

(g/cm3)

4.0-5.0

4.0-5.0

4.0-5.0

5.0-5.5

5.5-5.8

5.8-6.0

5.8-6.0

5.8-6.0

5.8-6.0

5.8-6.0

5.8-6.0

5.8-6.0

6.0-6.2

6.0-6.2

6.0-6.4

6.0-6.4

6.0-6.4

6.0-6.4
